L17 NSK

Name: L17 NSK Suppliers - Qualified L17 NSK Distributor, Wholesaler | HK BEARING - Bearing Group
Brand: Bearing
SKU: 299024813

L17 NSK Magneto Bearing 17x40x10mm Angular Contact Separate Permanent Motor Ball Bearings in stock
Stock available for fast delivery,contact me for a quick quotation
Sales manager:Livia
Whatsapp:+86 15628905595
Email: livia@hkbearingservice.com

Send InquiryChat Now

Description

L17 Angular Contact ball Bearing

Products Description

Bearing type : Angular Contact Ball Bearing

Model No. : L17

d (inside diameter): 17mm

D (outside diameter): 40mm

B (width):10mm

Weight: 0.057KG

Brand: All brand available or customize your own brand

Package : Single color box or customized as your request

Delivery time : 3-5 working days for stock items

Shipment : Small Package By Express DHL/UPS/FEDEX

Heavy cargos By air / By sea

send me inquiry directly for a quick quotation

whatsapp: +86 15628905595

livia@hkbearingservice.com

●Large stock ●High quality ●competitive price ●quick delivery

Let's get our bearings turning in the world

Products recommended

Hot selling Angular Contact Ball Bearing

★ 305288 DA SKF

★ 7238B/DB NSK

★ 3306-BD-XL-2Z FAG

★ QJ1960M

★ QJ 212 N2MA/C3

★ QJ 311N2MA C3 SKF

★ QJ324-N2-MPA FAG

★ QJ10/530-N2-MPA SKF

► Learn more angular contact ball Bearings

we also offer other same series magneto Magnetic motor bearing ▼

Magneto Magnetic motor bearing

Basic Load Ratings(Kgf)		Boundary Dimensions(mm)					Basic Load Ratings(kgf)		Limiting		Abutment and Fillet			Mass(kg)
Basic Load Ratings(Kgf)		Boundary Dimensions(mm)					Basic Load Ratings(kgf)		Speeds(rpm)		Dimension(mm)
E series	EN Series	d	D	B,T	r	r1	Dynamic	Static		Oil	Ds(min)	dh(max)	R(max)
E series	EN Series	d	D	B,T	r	r1	C	C0	Grease	Oil	Ds(min)	dh(max)	R(max)
E4	EN4	4	16	5	0.3	0.2	122	24	34000	40000	5.6	14.4	0.15	0.005
E5	EN5	5	16	5	0.3	0.2	122	24	34000	40000	6.6	14.4	0.15	0.005
E6	EN6	6	21	7	0.5	0.3	224	40	30000	36000	8.5	18.5	0.3	0.011
E7	EN7	7	22	7	0.5	0.3	254	40	28000	34000	9.5	19.5	0.3	0.012
	708	8	22	7	0.5	0.3	255	54	28000	34000	10.5	21.5	0.3	0.014
E8	EN8	8	24	7	0.5	0.3	255	54	28000	34000	10.5	21.5	0.3	0.014
6028		8	24	8	0.5	0.3	255	54	28000	34000	10.5	21.5	0.3	0.014
E9	EN9	9	28	8	0.5	0.3	335	73	24000	30000	11.5	25.5	0.3	0.022
E10	EN10	10	28	8	0.5	0.3	335	73	24000	30000	12.5	25.5	0.3	0.021
E11	EN11	11	32	7	0.5	0.3	270	75	22000	28000	13.5	29.5	0.3	0.027
E12	EN12	12	32	7	0.5	0.3	270	75	22000	28000	14.5	29.5	0.3	0.027
E13	EN13	13	30	7	0.5	0.3	270	75	22000	26000	15.5	27.5	0.3	0.021
E14	EN14	14	35	8	0.5	0.3	450	110	19000	24000	16.5	32.5	0.3	0.034
	7202	15	35	11	0.5	0.3	355	102	19000	24000	17.5	32.5	0.3	0.045
E15	EN15	15	35	8	0.5	0.3	355	102	19000	24000	17.5	32.5	0.3	0.033
N3048	-	15	37	8	0.5	0.3	355	102	19000	24000	17.5	32.5	0.3	0.033
BO15	-	15	40	10	1	0.6	570	153	14000	18000	20	35	0.6	0.055
E16	EN16	16	38	10	0.7	0.4	705	127	16000	20000	19.5	34.5	0.4	0.048
L17	-	17	40	10	1	0.5	450	134	14000	18000	22	35	0.6	0.053
E17	EN17	17	44	11	1	0.6	440	134	14000	18000	22	39	0.6	0.078
BO17	-	17	44	11	1	0.6	750	138	14000	18000	22	39	0.6	0.073
M17	-	17	44	10	1	0.6	750	138	14000	18000	22	39	0.6	0.073
E18	EN18	18	40	9	0.7	0.4	270	95	16000	20000	21	36.5	0.4	0.050
E19	EN19	19	40	9	0.7	0.4	270	95	16000	20000	22	36.5	0.4	0.048
E20	EN20	20	47	12	1.5	1	580	224	14000	17000	26	41	1	0.087
L20	-	20	47	14	1.5	0.7	580	224	14000	17000	26	41	0.7	0.100
M20	-	20	52	15	2	1	965	270	13000	16000	27	45	1	0.138
L25	-	25	52	15	1.5	1	565	240	12000	15000	31	45	1	0.122
M25	-	25	62	17	1.1	0.6	1250	375	11000	14000	31	55	0.6	0.217
L30	-	30	62	16	1.5	1	630	228	8000	11000	40	55	1	0.250
M30	-	30	72	19	2	1.5	630	228	8000	11000	40	65	1.5	0.400

Product range

We provide all kinds of bearings for you in standard & non-standard / Inch & metric.

Automotive bearings, tapered roller bearings, wheel bearings, needle bearings, deep groove ball bearings,cylindrical roller bearings,clutch, Cross shaft bearing, repair kits, Railway bearings...etc

Hot Tags: l17 nsk, l17 nsk suppliers, 305272 DA Bearing, Precision Angular Contact Ball Bearings, Angular Contact Ball Bearings

Previous: E20 NSK

Next: M 25 Magneto Bearing
